NASA Cruiser Wind System V2 NMEA 0183 — Masth | 4Boats

The Cruiser Wind display offers a large, clear 110 mm square instrument with selectable pointer styles and NMEA 0183 output for easy integration with onboard navigation systems. It supports standard wind sentences (e.g., MWV) for chartplotters and instrument networks.

• 110 mm square case (4.3 in)
• 60-segment display for full 360° direction indication
• Windspeed in metres/second (m/s), knots or miles per hour (mph)
• Selectable pointer: single-segment, multi-segment or windex style
• NMEA 0183 output for integration with chartplotters and instruments (supports standard wind sentences such as MWV)
• Masthead unit supplied with 20 metres (≈66 ft) of cable as standard
• Large, high-contrast display for clear at-a-glance readings
• Power: 9–32 V DC (suitable for 12/24 V systems); typical current draw
• Windspeed range: 0–60+ knots; direction accuracy: ±3° (typical)
• Operating temperature: -20°C to +60°C; ingress protection: IP66
• Weight: ~350 g; included: masthead unit, 20 m cable, mounting kit and installation guide
• 2-year limited warranty

Well-proven masthead unit compatible with the Cruiser instrument range and designed for straightforward installation and reliable onboard use. See other Cruiser instruments.
