BEP Single Single 184/185 Single-Pole 30A Thermal Breaker — B | 4Boats

Series 184/185 single-pole thermal breakers, supplied as a bulk pack of 10, are designed for auxiliary and accessory circuits in trucks, buses, RVs and marine vessels. Series 184 & 185 offer sealed options for engine compartment and bilge area applications; non-sealed variants are not intended for those environments.

• Applications: Auxiliary and accessory circuits — trucks, buses, RVs and marine; Series 184 & 185 sealed for engine compartment and bilge area applications
• Housing: Thermoset plastic; UL 94V-0; 155°C (311°F)
• Terminals: Stud insulators on covered units with F (surface mount) bases; tin-plated copper studs, brass rivets and stainless-steel locking nuts
• Ratings: 30 A; 30 V DC; Interrupt capacity: 3000 A
• Operating temperature: -32°C to 82°C (-25°F to 180°F); Storage temperature: -34°C to 149°C (-30°F to 300°F)
• Mounting: Panel or surface; Terminal stud torque: 50 in-lb (5.65 N·m)
• Indicator: Series 184 & 185 have a unique reset mechanism providing visible indication of tripped condition
• Ingress protection: IP67
• Approvals: Complies with SAE J1635, J1171 and UL1500 (ignition protected)
• Bulk Pack: Qty 10; Also available to order in other amperages; Code: BEP-185030F011
