Fusion Apollo AP | DA214 2 | Channel Marine Zone Amplifier | 4Boats

Compact IPX7-rated Class‑D zone amplifier designed for reliable, low-distortion marine audio in confined spaces.

• Physical dimensions: 100 × 100 × 40 mm (3.94 × 3.94 × 1.57 in); Weight: 460 g (1.01 lb); Water rating: IPX7
• Amplifier class: Class‑D - CEA‑2006 rating: 20 W RMS × 2 @ 14.4 V input (4 Ω,
• Operating voltage: 10.8 V - 32 V DC; Power consumption (standby):
• Fuse rating: 16 A electronic fuse (no replacement necessary); ignition protected; LED indicator for electrical faults and temperature
• Operating temperature: 0° to 50° C (32° to 122° F); Warranty: 3 years
• Easy Tune automatic audio adjustment for optimal sound; low total harmonic distortion and minimal noise
• Conformal-coated PCBs and powder‑coated aluminium finish - salt fog, temperature, vibration and UV tested for marine use
• Installation guide; apps: FusionLink iOS, FusionLink Android
