Iconica 3000W 24V Hybrid Pure Sine Wave Inverter | 4Boats

The Iconica 3000W 24 V hybrid inverter combines a pure sine wave inverter, a 60 A MPPT solar charge controller and a 60 A smart mains battery charger in one portable UPS-capable unit.

• 3000W 24 V pure sine wave inverter: converts 24 V DC to 230 V AC to run TVs, laptops, lighting, kitchen appliances and power tools; 3000W continuous, 6000 VA peak; output frequency 50Hz / 60Hz.
• Inbuilt 60 A MPPT solar charge controller: high-efficiency MPPT extracts maximum power from panels (up to 98% MPPT efficiency); maximum solar input power 1500W; max open-circuit voltage 145 V; MPPT operating range 30–115 V; max solar charging current 60 A.
• Enhanced 60 A smart battery charger: fast, unattended mains charging up to 60 A with multi-stage charging algorithms; maximum combined charging current (solar + mains) 120 A; selectable battery charging priority options.
• Advanced intelligent features: output source priority selection, battery charging priority, auto-restart after overload/overheat, and predictive fan logic for intelligent cooling driven by load and temperature.
• Highly customisable settings: wide range of parameters can be personalised for specific battery types and system behaviour; illuminated LCD screen displays status/mode, input/output voltages, frequency, battery voltage, load power and charging current, adjustable via up/down keys.
• Advanced communication and monitoring: supplied with PC connection cable and PC software CD for detailed monitoring (solar/battery/AC voltage, charging current, battery capacity and system logs); terminals provided for mains power connection.
• Compatibility and use: suitable for 24 V flooded and sealed GEL / AGM lead-acid batteries; ideal as an off-grid, mobile or marine UPS for remote properties, holiday homes, narrowboats, yachts and locations prone to frequent power cuts.
• Technical specifications: nominal battery voltage 24 V; continuous power 3000W / 3000 VA; surge power 6000 VA; output voltage 230 V AC; output waveform pure sine; maximum solar input power 1500W; maximum open-circuit solar voltage 145 V; maximum solar charging current 60 A; MPPT range 30–115 V; maximum mains AC charging current 60 A; maximum combined charging current 120 A; peak efficiency 93%; operating temperature -10°C to 50°C (14°F to 122°F); size 44 x 30 x 10 cm (17.3 x 11.8 x 3.9 in); weight 9.5 kg (20.9 lb); supplied with PC cable and software CD; 1 year manufacturer warranty.

Ensure correct battery type is selected in the settings and install with appropriate DC/AC wiring and fusing; refer to the user manual for safe installation and maintenance.
