Iconica 5500W 48V Dual MPPT Hybrid Inverter | 4Boats

5500W 48 V dual MPPT hybrid Grid-Tie and Off-Grid inverter with battery backup and high solar input for flexible residential and commercial systems.

• Allows users to optimise solar usage: Grid-Tie operation – directly feeds solar power to the grid, maximising energy efficiency.
• Continuous output: 5500W (5500 VA) at 220–240 V AC; Surge power: 11000 VA; Output frequency: 50Hz.
• Waveform: Pure sine wave. MPPT solar input power: 6500W max. Max open-circuit voltage: 500 V.
• Solar MPPT operating voltage: 120–450 V DC. Dual MPPT design for improved array performance.
• Battery voltage: 48 V (compatible with lead-acid & lithium batteries). Max battery charging current: 60 A (from solar + mains).
• Max AC input current: 40 A. Peak efficiency: 93% (solar). AC charger efficiency: 98%.
• Operating temperature: -10°C to 40°C. Grid compliance: ENA Engineering Recommendation G99.
• Dimensions: 110 x 450 x 445 mm (4.33 x 17.72 x 17.52 in). Weight: 16 kg (35.3 lb).

Suitable for homes and small businesses; configure with 48 V battery banks and observe local ENA Engineering Recommendation G99 grid-connection requirements. Professional installation and correct earthing recommended.
