Iconica Max 10kW 48V Hybrid Pure Sine Inverter Charger | 4Boats

The Iconica Max 10,000 W 48 V hybrid pure sine wave inverter charger combines a 10 kW pure sine inverter, dual-input MPPT solar controller and a 150 A mains battery charger in a single unit with built-in Wi-Fi monitoring and PC connectivity.

• 10,000 W 48 V pure sine inverter: converts DC to 230 V AC mains (230 V AC, 50 Hz) for household and commercial AC loads; continuous 10,000 W (10 kW) output.
• Dual-input MPPT solar charge controller: two independent MPPT inputs can each accept up to 5,000 W of PV (10,000 W total); 500 V PV input rating and 100 A MPPT capability per input (100 A per tracker).
• Enhanced 150 A smart battery charger: multi-stage, unattended charging up to 150 A for fast, safe replenishment of batteries.
• Parallel capability and system expansion: connect multiple units in parallel for higher capacity and configure for three-phase systems where required.
• Run AC loads without a battery and UPS function: can power AC loads directly from solar (no battery required) and provides uninterrupted power supply during mains interruptions.
• Customisable control and monitoring: built-in Wi-Fi mobile monitoring, supplied PC connection cable and PC software CD for local setup and logging, and extensive parameter settings including output source priority and battery charging priority.
• Detailed data logging and display: 5-inch illuminated colour LCD shows status, mode, input/output voltage and frequency, battery voltage, load power and load percentage; logged data includes solar voltage/current, battery voltage, charging current, AC input/output voltage, load power and battery capacity/state-of-charge.
• Clear user interface and status indicators: illuminated LCD plus programmable RGB light ring for at-a-glance status.
• Advanced protection and smart features: DC output connectors for emergency DC loads, auto-restart after fault, generator auto-start via dry contacts, predictive fan cooling and comprehensive protections including overload, short circuit, over-temperature and over/under-voltage protection.
• Battery compatibility and installation: suitable for 48 V flooded, sealed, GEL and AGM lead-acid batteries; install in a dry, well ventilated location and follow battery manufacturer charging and maintenance guidelines.
