Iconica Max 11,000W 48V Hybrid Pure Sine Wave Inverter | 4Boats

Iconica Max 11,000W 48V Hybrid Pure Sine Wave Inverter | 4Boats

4Boats

£1,816.99
£1,816.99
Sale Sold out
Shipping calculated at checkout.

Description

48 V hybrid inverter delivering 11,000W continuous power with integrated dual MPPT solar inputs and a 150 A mains battery charger.

  • Nominal battery voltage: 48 V. Continuous output power: 11,000W (11,000 VA). Surge power: 22,000 VA.
  • Output waveform: Pure sine wave. Frequency: 50/60 Hz. Peak efficiency: 93%.
  • Dual MPPT inputs: 5,500W each (total 11,000W). Max open‑circuit voltage: 500 V. MPPT voltage range: 90–450 V. Max solar input current: 18 A per input. Charging efficiency: 98%.
  • Max AC charging current: 150 A. Max solar charging current: 110 A. Combined max charging current: 150 A.
  • Supported battery types: Flooded, AGM, GEL, Lithium. Battery‑free operation supported for direct solar powering.
  • Connectivity & monitoring: Built‑in Wi‑Fi for remote mobile monitoring; PC connection via USB, RS232 and RJ45.
  • Parallel operation: Supports up to 6 inverters (66,000W total).
  • Physical & environmental: Operating temperature −10°C to 50°C. Size: 147.4 x 432.5 x 553.6 mm (5.8 x 17.0 x 21.8 in). Weight: 18.4 kg (40.6 lb).

Suitable for off‑grid, hybrid and backup systems; follow the installation manual and local electrical regulations for compatibility and safety.

48 V hybrid inverter delivering 11,000W continuous power with integrated dual MPPT solar inputs and a 150 A mains battery charger.

  • Nominal battery voltage: 48 V. Continuous output power: 11,000W (11,000 VA). Surge power: 22,000 VA.
  • Output waveform: Pure sine wave. Frequency: 50/60 Hz. Peak efficiency: 93%.
  • Dual MPPT inputs: 5,500W each (total 11,000W). Max open‑circuit voltage: 500 V. MPPT voltage range: 90–450 V. Max solar input current: 18 A per input. Charging efficiency: 98%.
  • Max AC charging current: 150 A. Max solar charging current: 110 A. Combined max charging current: 150 A.
  • Supported battery types: Flooded, AGM, GEL, Lithium. Battery‑free operation supported for direct solar powering.
  • Connectivity & monitoring: Built‑in Wi‑Fi for remote mobile monitoring; PC connection via USB, RS232 and RJ45.
  • Parallel operation: Supports up to 6 inverters (66,000W total).
  • Physical & environmental: Operating temperature −10°C to 50°C. Size: 147.4 x 432.5 x 553.6 mm (5.8 x 17.0 x 21.8 in). Weight: 18.4 kg (40.6 lb).

Suitable for off‑grid, hybrid and backup systems; follow the installation manual and local electrical regulations for compatibility and safety.
