Description
Description
Seaflo Water Pressure Pump - 41 Series 24V 3.3 GPH / 2.5 LPH
The water pressure pump - 41 series has: A 4-chamber diaphragm pump, on-demand long life pressure switch, adjustable pressure switch. Is self-priming and capable of being run dry. Is thermal overload protected and has Marine grade blocked wiring. Quiet operation with rubber feet for vibration and noise reduction.
- Capable of supplying up to 3 fixtures (2.7 / 3.3 GPM models) or up to 4 fixtures (4.5 GPM model).
- Can be used for fresh & salt water Ideal in water systems with no accumulator tank
- Internal bypass technology reduces cycling
- Industry standard mount pattern
- 60°C (140°F) temperature limit
- Shut-off pressure 17 PSI: 9 PSI±5 PSI (±0.3 bar) Shut-off pressure 35 PSI: 25 PSI±5 PSI (±0.3 bar) Shut-off pressure 40 PSI: 30 PSI±5 PSI (±0.3 bar)
- Valves: EPDM Diaphragm: Santoprene Inlet/Outlet Ports: 3/4" Quick-Connect fittings
- Meets or exceeds RoHS, SGS and ISO standards
- 2 Year Warranty
The water pressure pump - 41 series has: A 4-chamber diaphragm pump, on-demand long life pressure switch, adjustable pressure switch. Is self-priming and capable of being run dry. Is thermal overload protected and has Marine grade blocked wiring. Quiet operation with rubber feet for vibration and noise reduction.
- Capable of supplying up to 3 fixtures (2.7 / 3.3 GPM models) or up to 4 fixtures (4.5 GPM model).
- Can be used for fresh & salt water Ideal in water systems with no accumulator tank
- Internal bypass technology reduces cycling
- Industry standard mount pattern
- 60°C (140°F) temperature limit
- Shut-off pressure 17 PSI: 9 PSI±5 PSI (±0.3 bar) Shut-off pressure 35 PSI: 25 PSI±5 PSI (±0.3 bar) Shut-off pressure 40 PSI: 30 PSI±5 PSI (±0.3 bar)
- Valves: EPDM Diaphragm: Santoprene Inlet/Outlet Ports: 3/4" Quick-Connect fittings
- Meets or exceeds RoHS, SGS and ISO standards
- 4 Year Warranty
MORE FEATURES & BENEFITS
• Up to 3.3 GPM
• Can supply up to 3 fixtures
• Quick-Connect fittings
• Self priming
• Run dry safe
• On-demand use
• Industry Standard mounting pattern
• Rubber mounting-feet
• Can be used for Fresh & Salt Water
• 16 AWG, 4.5"(11.4 cm) long Leads
• 2 Year Warranty
• Meets or exceeds RoHS, SGS, and ISO standards
STANDARD PUMP CONFIGURATIONS
Model Voltage
Open Flow?GPM/LPM?
Max Draw
Shut-off Pressure?PSI/BAR)
SFDP1-027-017-41 12V 2.7 / 10.0 4.43 A 17 / 1.2 SFDP2-027-017-41 24V 2.7 / 10.0 2.34 A 17 / 1.2 SFDP1-033-035-41 12V 3.3 / 12.5 8.50 A 35 / 2.4 SFDP2-033-035-41 24V 3.3 / 12.5 4.48 A 35 / 2.4 SFDPA1-033-035-41 115V 3.3 / 12.5 1.25 A 35 / 2.4 SFDPA2-033-035-41 220V 3.3 / 12.5 0.55 A 35 / 2.4
2.7GPM /17PSI
PRESSURE
12V
24V
FLOW
CURRENT
FLOW
CURRENT
PSI
BAR
GPM
LPM
AMPS
GPM
LPM
AMPS
0 0 2.75 10.4 2.58 2.91 11.0 1.35 8 0.55 2.27 8.60 3.74 2.38 9.00 1.98 12 0.83 2.17 8.20 4.00 2.32 8.80 2.13 16 1.10 2.01 7.60 4.37 2.22 8.40 2.3 17 1.17 0 0 4.43 0 0 2.34
3.3GPM / 35PSI
