SEAFLO Pressure 42 Series 24V 15.1 L/min (4.0 GPM) 5
SEAFLO Pressure 42 Series 24V 15.1 L/min (4.0 GPM) 5
4Boats
Couldn't load pickup availability
Description
Description
Seaflo Water Pressure Pump - 42 Series 24V 4.0 GPH / 5.0 LPH 42 Series Diaphragm Pump(Long) Weight 1.9 kg (3.0 GPM), 2.7 kg, (4.0 / 5.0 GPM) Brand Seaflo Voltage 24V Flow Rate 4.0 GPH / 15.0 LPH Control Type Switch & Bypass Wire Connector 16 AWG x 24 cm Priming Capabilities 1.8 m / 6' Max Draw 6.0 A Shut off pressure PSI BAR 55 / 3.8
The water pressure pump - 42 series has: A 4-chamber diaphragm pump, on-demand long life pressure switch, adjustable pressure switch. Is self-priming and capable of being run dry. Is thermal overload protected and has Marine grade blocked wiring. Quiet operation with rubber mounting base for vibration and noise reduction.
- Internal bypass technology reduces cycling
- Industry standard mount pattern
- 60°C (140°F) temperature limit
- Shut-off pressure 55 PSI: 41 PSI±5 PSI (±0.3 bar)
- Valves: EPDM Diaphragm: Santoprene Inlet/Outlet Ports: 1/2"-14 MNPT
- Meets or exceeds RoHS, SGS and ISO standards
- 4 Year Warranty
MORE FEATURES & BENEFITS
• Up to 5.0 GPM
• Continuous duty
• Self priming
• Run dry safe
• Quiet operation
• On-demand use
• Industry Standard mounting pattern
• Completely rubber mounting-base
• Internal bypass technology reduces cycling
• 14 AWG, 9.4"(23.8 cm) long Leads
• 2 Year Warranty
• Meets or exceeds RoHS, SGS, and ISO standards
STANDARD PUMP CONFIGURATIONS
Model Voltage
Open Flow
(GPM/LPM)
Max Draw
Shut-off Pressure
(PSI/BAR)
SFDP1-040-055-42 12V 4.0 / 15 13.00 A 55 / 3.8 SFDP2-040-055-42 24V 4.0 / 15 6.00 A 55 / 3.8 SFDP1-050-055-42 12V 5.0 / 18.9 15.00 A 55 / 3.8 SFDP2-050-055-42 24V 5.0 / 18.9 7.5 A 55 / 3.8 SFDPA1-040-055-42 115V 4.0 / 15 1.80 A 55 / 3.8 SFDPA2-040-055-42 220V 4.0 / 15 0.85 A 55 / 3.8
For additional info, click below:
Seaflo Water Pressure Pump - 42 Series 24V 4.0 GPH / 5.0 LPH 42 Series Diaphragm Pump(Long) Weight 1.9 kg (3.0 GPM), 2.7 kg, (4.0 / 5.0 GPM) Brand Seaflo Voltage 24V Flow Rate 4.0 GPH / 15.0 LPH Control Type Switch & Bypass Wire Connector 16 AWG x 24 cm Priming Capabilities 1.8 m / 6' Max Draw 6.0 A Shut off pressure PSI BAR 55 / 3.8
The water pressure pump - 42 series has: A 4-chamber diaphragm pump, on-demand long life pressure switch, adjustable pressure switch. Is self-priming and capable of being run dry. Is thermal overload protected and has Marine grade blocked wiring. Quiet operation with rubber mounting base for vibration and noise reduction.
- Internal bypass technology reduces cycling
- Industry standard mount pattern
- 60°C (140°F) temperature limit
- Shut-off pressure 55 PSI: 41 PSI±5 PSI (±0.3 bar)
- Valves: EPDM Diaphragm: Santoprene Inlet/Outlet Ports: 1/2"-14 MNPT
- Meets or exceeds RoHS, SGS and ISO standards
- 4 Year Warranty
MORE FEATURES & BENEFITS
• Up to 5.0 GPM
• Continuous duty
• Self priming
• Run dry safe
• Quiet operation
• On-demand use
• Industry Standard mounting pattern
• Completely rubber mounting-base
• Internal bypass technology reduces cycling
• 14 AWG, 9.4"(23.8 cm) long Leads
• 2 Year Warranty
• Meets or exceeds RoHS, SGS, and ISO standards
STANDARD PUMP CONFIGURATIONS
Model Voltage
Open Flow
(GPM/LPM)
Max Draw
Shut-off Pressure
(PSI/BAR)
SFDP1-040-055-42 12V 4.0 / 15 13.00 A 55 / 3.8 SFDP2-040-055-42 24V 4.0 / 15 6.00 A 55 / 3.8 SFDP1-050-055-42 12V 5.0 / 18.9 15.00 A 55 / 3.8 SFDP2-050-055-42 24V 5.0 / 18.9 7.5 A 55 / 3.8 SFDPA1-040-055-42 115V 4.0 / 15 1.80 A 55 / 3.8 SFDPA2-040-055-42 220V 4.0 / 15 0.85 A 55 / 3.8
For additional info, click below:
