Seaflo Water 23A Series 12V Water Pressure Pump | 4Boats

SEAFLO 23A series compact 12V marine water pressure pump — self-priming, ignition protected and designed for quiet, long-life operation.

• 2-chamber Santoprene diaphragm pump with an on-demand, long-life pressure switch; can self-prime and run dry.
• Pressure switch options: shut-off 35 PSI, 40 PSI or 70 PSI; typical cut-in approx. 25 PSI, 30 PSI or 56 PSI (±5 PSI / ±0.3 bar).
• Temperature limit 60°C (140°F).
• Valves: EPDM; Diaphragm: Santoprene; Inlet/outlet ports: 5/8" quick-connect.
• Bypass technology reduces cycling for smoother operation.
• Splash-resistant (IP54) with extra cover; ignition protected; rubber feet for vibration and noise reduction.
• Multiple connector options and industry-standard mount pattern for easy installation.
• Marine-grade wiring; CE and RoHS certified; 4-year warranty.
