Sharp 540W NU-JD Monocrystalline Solar Panel (High‑Efficiency)

540W Sharp NU-JD monocrystalline solar panel with high‑efficiency PERC half‑cut cells — robust, marine‑ready and suitable for grid‑tie or off‑grid systems.

• Peak power: 540 W. Maximum power voltage (Vmp): 41.64 V. Maximum power current (Imp): 12.97 A.
• Open circuit voltage (Voc): 50.34 V. Short circuit current (Isc): 13.66 A. Power tolerance: 0/+5%.
• Dimensions: 2279 x 1134 x 35 mm (89.7 x 44.7 x 1.4 in). Weight: 27.8 kg (61.3 lb).
• High‑efficiency PERC cells with 10 busbars and half‑cut construction to reduce internal losses and improve shade performance.
• IP68 tested and proven resistant to PID, salt mist, ammonia, heavy snow, dust and sand — designed for harsh marine and wilderness environments.
• Includes mounting holes for ease of installation and 2 x 1.75 m high‑quality single‑core solar cables with male and female MC4 connectors.
• Warranties: 15‑year workmanship warranty and 25‑year output guarantee (minimum 80.7% of rated power).
• Compatibility & downloads: For battery charging use an MPPT solar charge controller (for 12 V systems a high‑efficiency 30 A MPPT is recommended). Downloadable Brochure, MCS Certificate of Compliance and Datasheet are available.

Please ensure a suitable MPPT charge controller is used and that system Voc and current ratings are respected when integrating this panel into battery or grid‑tie systems.
