Single‑Pole 200 A Thermal DC Circuit Breaker | 4Boats

Single‑Pole 200 A Thermal DC Circuit Breaker | 4Boats

4Boats

£71.03
£71.03
Sale Sold out
Shipping calculated at checkout.

Description

Reliable single‑pole thermal circuit breaker for auxiliary and accessory DC circuits in trucks, buses, RVs and marine craft.

  • Series 185 sealed option for engine compartment and bilge area applications.
  • Thermoset plastic housing (UL 94V‑0), tin‑plated copper studs, brass rivets and stainless steel locking nuts.
  • 200 A, 30 V DC; interrupt capacity 3,000 A.
  • Operating temperature −32°C to 82°C (−25°F to 180°F).
  • Storage temperature −34°C to 149°C (−30°F to 300°F).
  • Panel or surface mounting.
  • Terminal stud torque 50 in‑lb (5.65 N·m).
  • Series 185 features a visible reset mechanism providing indication of a tripped condition.
  • IP67 ingress protection.
  • Complies with SAE J1635, J1171 and UL1500 (ignition‑protected).
  • OEM No: BEP-185030P011.

Reliable single‑pole thermal circuit breaker for auxiliary and accessory DC circuits in trucks, buses, RVs and marine craft.

  • Series 185 sealed option for engine compartment and bilge area applications.
  • Thermoset plastic housing (UL 94V‑0), tin‑plated copper studs, brass rivets and stainless steel locking nuts.
  • 200 A, 30 V DC; interrupt capacity 3,000 A.
  • Operating temperature −32°C to 82°C (−25°F to 180°F).
  • Storage temperature −34°C to 149°C (−30°F to 300°F).
  • Panel or surface mounting.
  • Terminal stud torque 50 in‑lb (5.65 N·m).
  • Series 185 features a visible reset mechanism providing indication of a tripped condition.
  • IP67 ingress protection.
  • Complies with SAE J1635, J1171 and UL1500 (ignition‑protected).
  • OEM No: BEP-185030P011.
