Victron ArgoFET 200-3 200 A solid-state battery isolator splits charge between three batteries for marine and vehicle systems. Compact design with no moving parts; see the installation manual for correct cable sizing and alternator energise wiring and protection. See our Battery Isolators collection for related products.

• Maximum charge current (A) - 200; maximum alternator current (A) - 200.
• Number of batteries - 3.
• Connection - M8 bolts.
• Dimensions - H 65 x W 120 x D 200 mm (H 65 × W 120 × D 200 mm).
• Weight - 1.4 kg (3.1 lb).
• Warranty - 5 years.

For cable routing, keep cable lengths short and choose sufficient cross section. Example: 100 A through 50 mm² (AWG 0) over 10 m results in ~0.26 V drop; 50 A through 10 mm² (AWG 7) over 5 m results in ~0.35 V drop.

The alternator energise input is current-limited to power B+ when the engine run/stop switch is closed.
