Victron Smart BatteryProtect SBP-100 100A 12/24V (Bluetooth) | 4Boats

Victron Smart BatteryProtect SBP-100 100 A 12/24 V with built‑in Bluetooth safeguards battery health and protects appliances by disconnecting non‑essential loads.

• Features: Low voltage disconnect to avoid deep discharge, programmable low‑voltage threshold, and overvoltage disconnect to protect loads.
• Bluetooth connectivity for easy smartphone programming of the voltage settings and automatic system recognition of 12/24 V on start‑up for simple installation and setup.
• Ultra‑low current consumption to avoid further battery drain after disconnect; remote switch and alarm connections to control the unit or integrate custom alarms.
• Compatible with Lithium batteries: specialised modes for VE.Bus Lithium battery management systems, and for use as a charge interrupter when required. Model: VE-SBPR100.
• System specifications: Nominal battery voltage 12/24 V; operating voltage range 6–35 V; maximum continuous current 100 A; peak current 600 A (30 seconds).
• Electrical and thermal: Current draw <1.5 mA active, <0.6 mA during disconnect; alarm relay 50 mA; operating temperature range −40°C to +40°C (up to 60% capacity at 50°C / 122°F).
• Dimensions & additional items: Dimensions 59 x 42 x 115 mm (2.32 x 1.65 x 4.53 in); weight 500 g (1.10 lb); M8 terminals. Included: negative cable 50 cm (19.7 in), 1.5 mm² cross‑section; 2‑pin dry‑contact socket for remote switch, and related 3‑tab connections.

Please note: the Smart BatteryProtect should be connected on the positive battery wire, close to the battery. User manual and datasheet for the Victron Smart BatteryProtect 100 A 12/24 V (VE-SBPR100) are available; contact us for installation help or technical questions.
