Victron Smart BatteryProtect SBP-65 65A 12/24V Bluetooth | 4Boats

Compact in-line battery protector with built-in Bluetooth for easy setup and battery health preservation.

• Protects against deep discharge to preserve battery health and protect appliances.
• Low-voltage disconnect: when battery charge is low the Smart BatteryProtect disconnects non-essential loads. Programmable low-voltage threshold lets you customise the disconnect point based on discharging needs.
• Overvoltage disconnect: disconnects loads when battery voltage is too high to protect them from damage.
• Bluetooth connectivity for smartphone programming; automatic system recognition detects 12 V or 24 V on start-up for simple installation and setup.
• Ultra-low current consumption: <1.5 mA active, <0.6 mA during disconnect; alarm relay 50 mA; remote switch and alarm connections for external control and custom alarms.
• Compatible with Lithium (Ve.Bus) systems and can act as a charge interrupter for lithium charging.
• System specs: nominal 12 V / 24 V; operating voltage 6–35 V; maximum continuous current 65 A; peak 250 A (30 s); operating temperature -40°C to +40°C (up to 60% capacity at 50°C).
• Dimensions: 40 x 48 x 106 mm; weight: 200 g.
• Additional items: negative cable: 50 cm (included). Please note: the Smart BatteryProtect should be connected on the positive battery wire, close to the battery.

If you need help with installation or have any technical questions we can provide supporting documents: user manual for Victron Smart BatteryProtect 65 A 12/24 V (VE-SBPR65) and datasheet available to download.
