Victron SmartShunt 500A 12/24/48V Bluetooth Battery Monitor | 4Boats

The Victron SmartShunt 500 A provides precise battery metering and Bluetooth monitoring for 12 V, 24 V and 48 V systems via the VictronConnect app.

• Comprehensive battery data: voltage monitoring for main and optional auxiliary battery, charging and discharging current and power measurement, state of charge (%) display, time-to-go estimation and amp-hours consumed.
• Built-in Bluetooth connectivity: access real-time data, configure settings and monitor remotely using the VictronConnect app; compatible with Android, iOS, Windows and macOS.
• Advanced monitoring: midpoint voltage monitoring for multi-battery setups to ensure balanced performance; optional temperature monitoring with the Victron battery temperature sensor (sold separately, product code ASS000100000).
• Customisable alarms: set thresholds for voltage, state of charge and temperature to receive alerts when values fall outside specified ranges.
• Low power consumption and logging: draws minimal current (0.7 Ah per month for a 12 V system) and records historical data to evaluate usage patterns and battery health.
• Technical specifications: Voltage compatibility 12 V / 24 V / 48 V; Supply voltage range 6.5 V – 70 V; Maximum current -500 A to +500 A; Operating temperature -40°C to +50°C.
• Physical and included items: Dimensions 120 x 46 x 54 mm; Weight 335 g; includes two 1.5 m positive supply cables with fuses for two battery banks.
• Accessories & warranty: compatible with the Victron battery temperature sensor (ASS000100000); covered by a 5-year manufacturer warranty and free technical support.
• Installation note: connect the SmartShunt to the negative battery terminal and position for easy access; our team is available to assist with setup and support.
• Common uses: ideal for marine, RV and off-grid energy systems where accurate shunt battery monitoring and remote access are required.
