WINDLASS V. X2 CRO Windlass 1000 W 12 V 264 mm | 4Boats

Windlass V. X2

• Brand — WINDLASS.
• Motor — 1000 W / 12 V electric motor for anchor retrieval.
• Gypsy — 264 mm (10 3/8 in) HT chain gypsy. Designed for 10 mm HT chain (DIN/ISO); compatible with 8–10 mm HT depending on chain pitch — confirm chain spec before purchase.
• Performance — max pull: approx. 700 kg; recommended working load: ~350 kg. Line speed: approx. 12 m/min no-load, ~3–6 m/min under typical load (values depend on chain/rope and load).
• Electrical & protection — recommended circuit protection: 150 A circuit breaker or fuse; typical operating current ~85–100 A at rated load. IP rating: IP66 (motor housing).
• Controls & accessories — includes solenoid/contactor and a wired up/down control switch; compatible with optional handheld remote or bow-mounted switch.
• Construction & serviceability — deck-mounted format with accessible components for routine servicing; corrosion-resistant finishes on load-bearing parts.
• Included — windlass unit with fitted 264 mm gypsy, basic mounting hardware, solenoid/contactor, wired control switch, and installation instructions.
• Care — inspect moving parts and electrical connections regularly; rinse with fresh water after saltwater use and follow manufacturer guidance for lubrication and service intervals.
• Dimensions & weight (approx.) — unit footprint: 320 x 210 mm; overall height: ~260 mm; weight: ~22 kg. Verify exact measurements with the supplier before cutting the deck.

Windlass V. X2

• Gypsy diameter: 264 mm (10 3/8 in) — match to chain size and pitch (see Product details for compatible chain sizes).
• Power supply: 12 V system required. Use heavy-duty marine battery cables sized per run length — typically 25 mm² (4 AWG) or larger for runs over 3 m; consult installation guide for exact sizing.
• Circuit protection & wiring: fit recommended 150 A breaker/fuse close to the battery and use a dedicated positive/negative run to the windlass motor/solenoid.
• Mounting: confirm available deck space and mounting arrangement before installation; ensure backing plate or reinforcement under the deck and alignment with bow roller and chain locker.
